Model Number | EY20 |
---|
Labeled Power (hp) | 5.0hp |
Bore x Stroke (mm) | 67x52mm |
Piston Displacement (cc) | 183cc |
Maximum Output (kw / hp / rpm) | 3.7 | 5.0 | 2000 |
Continuous Output (kw / hp / rpm) | 2.6 | 3.5 | 1800 |
Maximum Torque (nm / kgf.m / rpm) | 18.6 | 1.9 | 1400 |
Carburettor | Horizontal draft, float type |
Direction of Rotation | Counter-Clockwise Facing P.T.O Shaft |
Fuel Type | Petrol |
Fuel Tank | 3.8L |
db @ 7m | 69db |
Oil Capacity (L) | 0.6L |
Lubricant | SAE 10W-30, 20W, 30W |
Lubrication | Mechanical Splashing Type |
Governor | Centrifugal flyweight type |
Ignition System | Transistorised |
Engine Features | Air cooled, 4-cycle, upright single cylinder, side valve, horizontal P.T.O Shaft |
Starting System | Recoil Start |
Type of Gear Reduction | 1/2 Gear Type |
Dry Weight (kg) | 16kg |
|
|
|
|
